Asus ExpertBook B5 Flip (B5302F)

Asus ExpertBook B5 Flip (B5302F)

Core Specifications

Processor: Intel® Core™ i7-1165G7 (4 cores, 8 threads, up to 4.7 GHz)

Graphics: Intel Iris Xe Graphics

Display: 13.3″ Full HD (1920×1080) touchscreen with stylus support, anti-glare, 300 nits brightness, 100% sRGB color gamut

Memory: 16GB DDR4 onboard, expandable up to 48GB via one SO-DIMM slot

Storage: 1TB M.2 NVMe PCIe 3.0 SSD, with support for dual M.2 drives and RAID configurations

Battery: Options include a 33Wh 2-cell or a 66Wh 4-cell Li-ion battery

Weight: Approximately 1.20 kg (2.65 lbs.)

Operating System: Windows 11

️ Upgrade and Disassembly Insights
Accessing the internal components involves removing 10 Phillips-head screws and gently prying off the bottom panel. Inside, you’ll

Memory: A single SO-DIMM slot for RAM expansion, in addition to the soldered memory.

Storage: Two M.2 PCIe x4 slots, allowing for storage upgrades or RAID configurations.

Cooling System: Comprises a single heat pipe, heat sink, and a small fan, with additional cooling over the VRMs.

Note: Opting for the 66Wh battery variant is advisable for extended battery life.

Security and Durability Features
Security: Equipped with TPM 2.0, a fingerprint sensor integrated with the power button, BIOS and HDD password protection, and a Kensington lock slot.

Durability: Meets US MIL-STD 810H military-grade standards, ensuring resilience against various environmental conditions.

Connectivity and Ports
USB Ports: 1x USB 3.2 Gen 2 Type-A, 2x Thunderbolt™ 4 (USB4 compliant)

Display Outputs: 1x HDMI 2.0b

Networking: 1x micro HDMI (RJ45 LAN)

Audio: 1x 3.5mm combo audio jack

Wireless: Wi-Fi 6 (802.11ax) and Bluetooth® 5.2
